Madison Solar Car Initiative

James Madison High School
San Antonio, Texas
Dr.Joe Dungan, Team Advisor

Team Data
Team Captain Valerie Gamao
Vehicle Name Solar Ray II
Web Site http://madisonsolar.weebly.com/

Vehicle Data
Vehicle Length 4.96 m
Vehicle Width 1.67 m
Vehicle Height 1.06 m
Vehicle Weight
(without driver)
286.4 kg
Batteries Four Concorde Batteries
25.9 kg, 66 Ah per battery
Solar Cells Cell Manufacturer: Suntech STP-275 Multi Si
Number of cells: 6 panels
Efficiency: 14.2%
Brakes Type 1: MCP Big Bore 600535 [front]
Type 2: MCP Big Bore 600535 [rear]
Motor Motors & Armatures Inc. Mars 4201 BLDC
19 hp
